How to Record IPTV on a MAG Box (2026 Step-by-Step Guide)

To record IPTV on a MAG box, plug a FAT32- or NTFS-formatted USB drive into the box’s USB port, highlight the live channel or an EPG listing, press the red button on your remote, then confirm with YES. The recording saves straight to the USB drive and appears in the Recordings (or USB Media) section of the main menu for playback later.

MAG set-top boxes from Infomir are built around a proper PVR (personal video recorder) engine, not just a catch-up shortcut, which is why they remain a favourite for households that want dependable, offline-safe recordings of live IPTV. This guide goes beyond the basic red-button steps that most tutorials stop at: it explains why recording sometimes doesn’t appear as an option at all, how MAG recording differs from catch-up TV, realistic storage math so you don’t fill a drive mid-film, model-specific quirks across the MAG 254 through MAG 520 range, and a full troubleshooting table for the errors people actually hit. If you’re on a smart TV instead of a MAG box, see our separate guide to recording IPTV on a Smart TV, which covers TiviMate DVR and PC/NAS setups rather than MAG’s built-in PVR.

Before You Start: What MAG Recording Actually Requires

Two things trip people up before they even reach the red button, and neither is covered by most guides.

• Your IPTV provider must enable recording server-side. The record/DVR function on a MAG box is a permission set in the Ministra (Infomir) portal that your IPTV service controls, not a fixed hardware feature. If the Recordings icon is missing from your menu entirely, recording has not been switched on for your channel list — contact your provider rather than troubleshooting the USB drive. All RevoIPTV plans ship with recording enabled by default.
• You need MAG IPTV set up and authenticated first. If you haven’t loaded your portal URL yet, complete How to set up IPTV on a MAG box before attempting to record — the record option won’t appear on an unauthenticated box.

What You Need

• A MAG set-top box (MAG 254/256, 322/324, 420/422, 520/522, or newer)
• A USB flash drive or external USB hard drive, formatted FAT32 (universal compatibility, 4 GB per-file cap) or NTFS (no practical file-size limit, better for films and sports)
• An active IPTV subscription with recording enabled — see RevoIPTV pricing and subscriptions
• The USB drive inserted before you power on the box — MAG detects storage at boot far more reliably than during a hot-swap mid-session

How to Record IPTV on a MAG Box

Step 1 — Insert and let the box detect your USB drive

Power off the MAG box, insert the USB drive, then power back on. Give it 10–20 seconds after boot for the storage to mount before opening any menus.

Step 2 — Find the channel or programme

Tune to the live channel directly, or press the EPG button to open the Electronic Programme Guide and locate either the currently airing show or a future one you want to schedule.

Step 3 — Press the red button

With the channel or programme highlighted, press the red button on your remote. This opens the record confirmation overlay — this is the single control MAG uses for both instant and scheduled recording.

Step 4 — Confirm with YES

Select YES and press OK. For a live programme, recording starts immediately. For a future EPG entry, it’s queued and will start automatically at broadcast time — you don’t need the box switched to that channel, or even powered on standby, for a scheduled recording to fire on most firmware.

Step 5 — Check the red dot

Return to the EPG or channel list. Anything actively recording or scheduled shows a small red dot next to the listing, so you can confirm it queued correctly without waiting for playback.

Step 6 — Play back or manage recordings

Open the main menu and select Recordings (on some firmware builds this is under USB Media instead). Highlight a title and press OK to play, or press the red button again on a saved recording to delete it and free up space.

Catch-Up vs. Recording on MAG: Which Should You Use?

Most competing guides only cover the record button and never explain that MAG boxes actually offer two different ways to watch missed content — and picking the wrong one causes most of the ‘my recording disappeared’ confusion.

If your provider supports catch-up, you often don’t need to record at all for anything within the last few days — see how to use catch-up on MAG for the full walkthrough. Reach for USB recording when you want a permanent, offline copy, or when the programme falls outside your catch-up window.

How Much USB Storage Do You Actually Need?

A rough planning rule: standard-definition recordings run about 0.3–0.6 GB per hour, while HD channels typically use 1–2 GB per hour. A 32 GB USB drive comfortably holds roughly 15–25 hours of HD recording. Keep at least 10–15% of the drive free at all times — recording to an almost-full drive is the most common cause of a recording stopping abruptly or the saved file playing back corrupted.

Does Recording Work the Same on Every MAG Model?

The red-button workflow is consistent across the range, but capability and reliability vary:

• MAG 254/256: Supports USB recording but is the oldest common model in use — expect slower USB write speeds, so favour a fast USB 3.0 stick even though the port itself is USB 2.0.
• MAG 322/324: Single-tuner devices. They can record and let you watch the same stream simultaneously, but you generally cannot record one channel while freely watching an unrelated one — this is a hardware limitation, not a bug.
• MAG 420/422 and 520/522: Newer chipsets with 4K support and generally more stable USB recording performance; still single-tuner on most units, so the same watch/record overlap rule applies.

Whatever model you own, confirm the exact menu wording with the official Infomir site, since firmware updates occasionally relabel the Recordings menu as USB Media.

Tips for More Reliable MAG Recordings

• Use a fast drive. A USB 3.0 stick or small USB SSD reduces dropped frames on HD streams even in a USB 2.0 port.
• Format as NTFS for anything over 30–40 minutes. FAT32’s 4 GB per-file cap is easy to hit on an HD film or a full football match.
• Don’t hot-swap. Insert the drive before boot rather than while the box is already running.
• Schedule ahead via EPG rather than relying on being home to hit the red button live.
• Periodically offload recordings to a computer to keep the drive under 85% full and avoid corruption on long recordings.

Troubleshooting MAG Recording Problems

For more MAG walkthroughs, browse the RevoIPTV tutorials hub, or set up your free IPTV trial to test recording before committing to a full plan. It’s also worth organising your most-recorded channels with MAG’s Favourites list, and if you’re still deciding whether a MAG box is right for you, our what is a MAG box guide compares the full model lineup. Full command reference and menu terminology are documented on the official Infomir/Ministra documentation site.

FAQ

Can you record IPTV on a MAG box?

Yes, provided your IPTV provider has recording enabled on your plan. Plug in a FAT32- or NTFS-formatted USB drive, press the red button on a live channel or EPG listing, and confirm YES to start recording — no extra software or hardware needed.

Why is there no Recordings option on my MAG box?

Usually because recording hasn’t been switched on server-side by your IPTV provider, or because no USB drive is currently detected. Confirm with your provider first, since this is the most common cause and isn’t something you can fix from the box’s settings alone.

What’s the difference between catch-up and recording on MAG?

Catch-up TV streams recently aired programmes from your provider’s servers, usually for 24–72 hours, and needs no setup. Recording saves a permanent local copy to your own USB drive that works offline and doesn’t expire on a provider timer.

What USB format does a MAG box need for recording?

Both FAT32 and NTFS work. FAT32 is universally compatible but caps individual files at 4 GB (roughly 30–40 minutes of HD). NTFS removes that cap, so it’s better for films, sports, or anything longer.

Can I schedule a recording in advance on a MAG box?

Yes. Open the EPG, select a future programme, press the red button, and confirm YES. The box records automatically at the scheduled time without you needing to be on that channel when it starts.

Can I record one channel while watching another on MAG?

Generally no. Most MAG boxes, including the 322/324 and 420 series, are single-tuner, so recording and live viewing share the same stream. You can usually keep watching the channel being recorded, but freely switching to an unrelated channel can interrupt the recording on some firmware.
