How to Set Up TiviMate IPTV Player (2026 Guide: Playlist, EPG & Premium Features)

To set up TiviMate IPTV once the app is installed, open it, tap Add Playlist, choose Xtream Codes login (or M3U URL if that’s what your provider gave you), enter your server address, username, and password, then tap Next — your live channels, EPG, and video-on-demand library load automatically. This guide focuses on configuring the player itself: playlists, the programme guide, favourites, and the Premium features that make TiviMate worth using over a stock IPTV app.

If you already have TiviMate installed and just need help getting your device set up in the first place, see our separate walkthroughs for configuring TiviMate on a Fire TV Stick and installing TiviMate on Firestick and Android. This article picks up right after installation and covers everything you do inside the app day to day. If you don’t have a service yet, grab a RevoIPTV free trial so you have live credentials to follow along with.

What You Need Before You Start

• TiviMate already installed on your Android, Fire TV, or Google TV device
• Your IPTV credentials: server address (with port), username, and password — or a single M3U playlist URL — from your provider’s welcome email or dashboard
• A stable connection of at least 10 Mbps for HD, 25 Mbps for 4K; Ethernet is strongly recommended over Wi-Fi

Adding a Playlist to TiviMate: Xtream Codes vs M3U

TiviMate supports two playlist formats, and choosing the right one matters because it changes how much manual configuration you’ll do afterward.

Option 1: Add a Playlist via Xtream Codes

1. On the TiviMate home screen, select Add Playlist.
2. Choose Xtream Codes login and tap Next.
3. Enter your server address exactly as provided, including the port (for example, http://provider.example.com:8080), then your username and password.
4. Leave Include VOD checked if you want movies and series alongside live channels.
5. Tap Next. TiviMate authenticates against the server and pulls channels, categories, EPG, and catch-up availability in one pass — this typically takes 10–60 seconds depending on how many channels your plan includes.

Xtream Codes is the method we recommend to RevoIPTV subscribers because it configures the EPG for you and exposes catch-up/archive automatically where the plan supports it — no separate XMLTV step required.

Option 2: Add a Playlist via M3U URL

1. Select Add Playlist, then choose M3U Playlist instead of Xtream Codes.
2. Give the playlist a name so you can identify it later if you add more than one.
3. Paste the full M3U URL your provider supplied and tap Next.
4. TiviMate downloads and parses the channel list. Because M3U alone carries no schedule data, jump to the EPG section below to add a guide manually.

Note that a raw .m3u file, rather than a hosted URL, can also be loaded from local/USB storage using the same screen — useful if your provider only emails you a downloadable file.

Setting Up the EPG (TV Guide)

The Electronic Programme Guide is what turns a channel list into an actual TV schedule with show titles, times, and descriptions. This is the step most first-time TiviMate users skip or get wrong, and it’s the single biggest source of “my guide is empty” complaints.

If you connected via Xtream Codes

EPG data is pulled in automatically with the playlist. If it looks empty right away, give it a few minutes — large guides for services with thousands of channels can take 2–5 minutes to fully populate on first sync.

If you connected via M3U

1. Go to Settings → Playlists, select your playlist, then open EPG.
2. Choose Add EPG source and paste the XMLTV URL your provider gave you.
3. Save, then return to Settings → EPG and tap Update EPG now to force an immediate sync.

Keep the guide current automatically

In Settings → EPG → Update interval, set an automatic refresh — every 12 or 24 hours overnight is the sweet spot. This avoids re-downloading a multi-megabyte guide file while you’re actively watching, which is a common cause of momentary buffering.

Navigating TiviMate: Core Features

TiviMate’s interface is built around remote-control navigation rather than touch, which is part of why it’s rated the most polished IPTV player on Android TV and Fire TV.

TV Guide grid

While watching, press OK and select TV Guide to see a full grid of what’s airing now and next across every channel in your playlist.

Quick settings panel

Hold OK for about two seconds during playback to open the quick panel, where you can toggle:

• Subtitles/CC and audio track
• Add to Favourites — pins the channel to a dedicated shortcut row on the home screen
• Catch-Up — rewind to already-aired content, when your provider supports it
• Recording — Premium only, covered below

Favourites and groups

Organising channels early makes a real difference in daily use. Add your regular channels to Favourites, then reorder channel groups under Settings → Interface → Channel list so sports, news, or kids’ content sit at the top instead of buried in an alphabetical list of hundreds of channels.

Parental controls

Under Settings → Parental control, you can PIN-lock specific channel groups (adult content, premium sports tiers, etc.) so they require a code to open — useful on a shared living-room device.

TiviMate Premium: What You Actually Get

TiviMate’s free tier covers a single playlist and standard playback, which is enough for most casual viewers. TiviMate Premium is a one-time purchase through the companion app (rather than a subscription tied to your IPTV provider) and unlocks:

• Multiple playlists — run two or more IPTV services (or a live service plus a separate VOD list) from one interface
• Recording — scheduled and manual DVR-style recording to internal storage or a connected USB drive
• Extended catch-up/archive access where your provider supports longer look-back windows
• Custom UI options — panel layout, channel numbering, and backup/restore of your configuration across devices

Adding a second playlist (Premium)

1. Go to Settings → Playlists.
2. Tap the + icon and choose Xtream Codes or M3U, exactly as you did for your first playlist.
3. Each playlist appears as its own source; you can merge them into one channel list or keep them separate under Settings → Interface.

Tips for a Smoother TiviMate Experience

• Use Ethernet where possible. A wired connection meaningfully cuts buffering on HD and 4K streams versus Wi-Fi, especially on older Fire TV Sticks with weaker antennas.
• Schedule EPG updates for overnight hours. Large guides download while you sleep so they’re ready the moment you turn the TV on.
• Set channel groups up front. Five minutes spent organising favourites and hiding unused groups saves scrolling every single time you sit down to watch.
• Match your plan to your household. If you’re adding a second playlist or streaming on multiple screens at once, check your RevoIPTV plans and pricing to make sure your connection limit covers it.
• Keep TiviMate updated, but read the changelog first. TiviMate ships frequent updates; if your setup is working well, there’s no harm holding off a version if a release note mentions known issues.

Looking for a different player instead? Compare options on the supported IPTV applications page, or browse the full RevoIPTV tutorials hub for setup guides across every device we support. General account and billing questions are answered on our FAQs page, and IPTV resellers can find bulk credential handling details on the reseller packages page.

Installing TiviMate on Firestick and Fire TV

TiviMate is not listed in the Amazon Appstore, so Fire TV Stick and Fire TV Cube owners have to sideload the APK. It only takes a few minutes.

1. From the Fire TV home screen, search for and install the free Downloader app.
2. Go to Settings > My Fire TV > Developer Options and turn Install unknown apps on for Downloader (on older sticks this is Apps from Unknown Sources).
3. Open Downloader, enter the current TiviMate APK link in the URL box, and let it download.
4. Choose Install, then Open. Add your playlist exactly as you would on any other Android device.

Because the Fire TV remote has no dedicated buttons, use the on-screen menu (long-press the select button) to reach settings, favourites and recording controls.

Which Devices Actually Run TiviMate

TiviMate is an Android-only app. It runs on Android TV boxes, the NVIDIA Shield, Chromecast with Google TV, Fire TV devices (via sideload) and Android phones or tablets. It is not available for iPhone, iPad, Apple TV, Samsung Tizen or LG webOS smart TVs. If you use one of those platforms, choose a cross-platform player such as IPTV Smarters Pro (iOS and Apple TV) or a native Apple TV client instead, using the same Xtream Codes or M3U details from your provider.

Free vs Premium: Cost and How to Upgrade

The free build is enough to watch live TV with one playlist and an EPG. Recording, catch-up, multi-view and multiple playlists are locked behind Premium, which you buy through the separate TiviMate Companion app on Google Play, then sign in with the same account on your streaming device to activate it.

Recording Live TV and Using Catch-Up

Recording needs Premium. Once activated, open the TV guide, highlight a current or upcoming programme and choose Record to schedule it, or start an instant recording from the playback menu. TiviMate saves files to internal storage by default; you can point it at a USB drive or a networked SMB/NAS share under Settings > Recordings for large libraries, since HD channels use roughly 2-4 GB per hour. For channels your provider supports, a Catch-Up label appears in the guide, letting you replay programmes from the past few days without recording anything. If timings look off, correct them under Settings > EPG > Time shift.

Related guides on RevoIPTV: installing TiviMate on a Fire TV Stick · IPTV Smarters Pro for iOS and other platforms · the iPlayTV app on Apple TV · recording IPTV on a smart TV · start a free RevoIPTV trial

FAQ

Does TiviMate work with any IPTV provider?

Yes. TiviMate is provider-agnostic — it supports the Xtream Codes API and standard M3U/XMLTV formats used by virtually every IPTV service, including RevoIPTV, rather than being tied to one company’s content.

Why is my TiviMate EPG empty or not loading?

Most often this means the EPG hasn’t finished its first sync, the playlist was added via M3U without a separate XMLTV EPG URL, or your plan doesn’t include guide data. Open your playlist, tap Update, then go to Settings → EPG and tap Update EPG now.

Do I need TiviMate Premium to use IPTV normally?

No. Free TiviMate handles one playlist with full live-channel, VOD, and EPG functionality. Premium is only necessary if you want recording, multiple simultaneous playlists, or extended customisation.

Can TiviMate record live TV?

Yes, but only with Premium. Hold OK for two seconds during playback and select Record. Recordings save to internal storage or a connected USB drive, so check available space before scheduling anything long.

What’s the difference between Xtream Codes and M3U in TiviMate?

Xtream Codes is an API connection that authenticates with your provider’s server and pulls channels, VOD, and EPG together automatically. M3U is a static playlist file or link that lists channel streams only — EPG has to be added as a separate XMLTV source.

How many devices can I use one TiviMate playlist on?

That depends on your IPTV subscription’s connection limit, not TiviMate itself — the app can be installed on unlimited devices, but simultaneous streams are capped by your plan. Check your provider’s connection allowance if you plan to add a playlist on more than one TV.

Is TiviMate available for iPhone or Apple TV?

No. TiviMate is an Android-only app, so it will not install on iPhone, iPad or Apple TV. Apple users should set up the same subscription in IPTV Smarters Pro or a native Apple TV player using their Xtream Codes or M3U details.

How much does TiviMate Premium cost in 2026?

Premium is roughly $9.99 per year or about $33.99 as a one-time lifetime payment. You buy it inside the TiviMate Companion app on Google Play, then sign in on your device to unlock recording, catch-up, multi-view and up to five playlists.

Do I need the TiviMate Companion app?

Only for Premium. The Companion app handles the purchase and licensing; after you buy and log in, the main TiviMate app unlocks the paid features automatically. The free version needs nothing extra.

Where does TiviMate store recordings?

By default recordings save to the device’s internal storage. Under Settings then Recordings you can switch the target to a USB drive or a networked SMB/NAS share, which is recommended because HD recordings use about 2-4 GB per hour.

How do I install TiviMate on a Firestick?

TiviMate is not in the Amazon Appstore, so sideload it: install the Downloader app, enable Install unknown apps for Downloader in Developer Options, then enter the TiviMate APK link in Downloader and install it.
